Applicable Standard ASTM 313
ASTM D1925
ASTM E308
Colour Type Opaque
Optical Geometry Reflect: di: 8°, de: 8° (diffused illumination, 8 degree viewing angle)
Integrating Sphere Size 48 mm
Spectrophotometric Mode Concave Grating
Sensor 256 image Element Double Array CMOS Image Sensor
Repeatability MAV/SCI: ΔE* ≤0.03
Display 3.5 inch TFT colour LCD, Capacitive Touch Screen
Interfaces USB
Spectral Interval 10 nm
Measurement Mode Single Measurement, Average Measurement
External Storage 2000 Standards : 20000 Samples
Location Method Camera View Finder Locating
Measured Reflectance Range 0 - 200 %
Measurement Time 2.6 s
Measuring Aperture Dual Aperture: 10mm/8mm & 5mm/4mm
Specular Component SCI & SCE
Colour Difference Formular ΔE*ab, ΔE*uv, ΔE*94, ΔE*cmc (2:1), ΔE*cmc (1:1), ΔE*00v, ΔE (Hunter)
Battery Life Time 5000 measurements with 8 hours
Other Colorimetric Index WI (ASTM E313, CIE/ISO, AATCC, Hunter)
YI (ASTM D1925, ASTM 313, TI (ASTM E313, CIE/ISO)
Metamerism Index MI, Staining Fastness, Colour Fastness, Colour Strength, Opacity
Displayed Data Spectrogram/Values, Samples Chromaticity Values,
Colour Difference Values/Graph, PASS/FAIL Result, Colour Offset
Inter Instrument Agreement MAV/SCI: ΔE* ≤0.15
Spectral Range 400 - 700 nm
Bandwidth 10 nm
Illuminants CIE Illuminant D65
CIE Illuminant A
CIE Illuminant C
CIE Illuminant D50
CIE Illuminant D55
CIE Illuminant D75
CIE Illuminant F1
CIE Illuminant F2
CIE Illuminant F3
CIE Illuminant F4
CIE Illuminant F5
CIE Illuminant F6
CIE Illuminant F7
CIE Illuminant F8
CIE Illuminant F9
CIE Illuminant F10
CIE Illuminant F11
CIE Illuminant F12
Portability Portable
Illuminant Life Span 5 years, more than 3 million measurements
Observer 2° / 10°
Environmental Conditions 0 - 40 °C, 0 - 85 % Relative Humidity (non condensing), Altitude < 2000 m
Stock Conditions -20 - 50 °C, 0 - 85 % Relative Humidity (non condensing)
Languages User Interface English, German, French, Spanish, Portuguese, Chinese
Dimensions 184 x 105 x 77 mm
